Altair S-LINE 2026.0

Altair S-LINE



Altair S-LINE is a powerful, specialized application dedicated to the analysis, design, and detailing of reinforced multi-span continuous beams with varying section sizes and reinforcement patterns for each span. Developed by Altair Engineering, S-LINE focuses on this specific yet critical structural element—providing engineers with a dedicated tool that understands the unique behavior of continuous beams: moment redistribution, support conditions, span interactions, and variable cross-sections.

Version 2026.0 continues Altair’s commitment to engineering precision and efficiency, offering comprehensive analysis capabilities, flexible section definition, detailed reinforcement design, and transparent code compliance checking. For engineers who work extensively with continuous beam systems, S-LINE delivers the focused functionality that general-purpose tools cannot match.



📏 Primary Users

This specialized structural engineering software is designed for:

• Structural Engineers & Concrete Designers analyzing and designing reinforced concrete continuous beams.

• Bridge Engineers designing multi-span bridge girders and continuous beam systems.

• Building Designers working with transfer beams, podium beams, and multi-span floor systems.

• Construction & Project Engineers verifying beam designs and optimizing reinforcement layouts.

• Academic Researchers & Educators teaching continuous beam behavior and design principles.





⚡ Key Features & Capabilities

📐 Multi-Span Continuous Beam Analysis

Span Configuration:

• Unlimited number of spans

• Variable span lengths

• Different section sizes per span

• Custom support conditions

• Cantilever and overhang options

Support Types:

• Simple supports (pinned/roller)

• Fixed and moment-resisting supports

• Elastic supports with user-defined stiffness

• Settlement and support displacement

• Intermediate column supports

Load Types:

• Distributed loads (uniform, varying)

• Concentrated point loads

• Moment loads

• Temperature effects

• Support settlement

• Prestressing forces

• Pattern loading for live loads

📊 Variable Section Design

Section Variations:

• Different beam widths per span

• Variable depths along spans

• Tapered and haunched sections

• Flanged sections (T-beams, L-beams)

• Rectangular sections with different dimensions

Reinforcement Patterns:

• Span-specific reinforcement design

• Top and bottom reinforcement

• Different bar sizes and spacing per span

• Curtailment and development considerations

• Support reinforcement zones

🧮 Structural Analysis Methods

Linear Elastic Analysis:

• Moment distribution

• Shear force and reaction calculations

• Deflection and rotation analysis

• Support reactions and settlement effects

Moment Redistribution:

• Plastic analysis for continuous beams

• Redistribution of moments per code provisions

• Ductility considerations

• Capacity design principles

Envelope Analysis:

• Multiple load case combinations

• Pattern loading envelopes

• Maximum and minimum moments

• Shear force envelopes

🔧 Reinforcement Design

Flexural Design:

• Positive and negative moment reinforcement

• Singly and doubly reinforced sections

• T-beam and flanged section design

• Compression reinforcement when needed

• Bar selection and optimization

Shear Design:

• Shear force calculations

• Stirrup design and spacing

• Inclined shear reinforcement

• Torsion effects when applicable

• Interface shear for composite sections

Serviceability Checks:

• Deflection calculations (short and long-term)

• Crack width control

• Vibration serviceability

• Fatigue considerations where relevant

📋 Code Compliance

International Design Codes:

• ACI 318 (American Concrete Institute)

• CSA A23.3 (Canadian Standards Association)

• Eurocode 2 (EN 1992)

• Other regional concrete codes

Comprehensive Checks:

• Strength limit states

• Serviceability limit states

• Ductility requirements

• Minimum and maximum reinforcement

• Bar spacing and cover requirements

• Development length verification

📈 Results Visualization

Graphical Output:

• Moment diagrams

• Shear force diagrams

• Deflection profiles

• Reinforcement layouts

• Utilization ratios color-coded

Tabular Results:

• Support reactions

• Critical section forces

• Reinforcement summaries

• Deflection values at key points

📊 Design Report Generation

Comprehensive Documentation:

• Complete design summaries

• Code check results with clause references

• Reinforcement details and schedules

• Material quantities

• Load case and combination information

Export Options:

• PDF reports for documentation

• Word documents for editing

• Excel spreadsheets for quantities

• Integration with other engineering tools

🔧 Optimization Features

Reinforcement Optimization:

• Minimize reinforcement quantities

• Bar size and spacing optimization

• Cost-effective design solutions

• Multiple design alternatives

Section Optimization:

• Iterative section sizing

• Span/depth ratio considerations

• Deflection-controlled optimization

• Material quantity minimization

🔄 Integration with Engineering Workflows

S-FRAME Compatibility:

• Seamless integration with Altair S-FRAME Analysis

• Import forces and moments from frame analysis

• Consistent modeling environment

• Unified analysis and design workflow

S-Concrete Integration:

• Shared material and design parameters

• Consistent reinforcement design philosophy

• Complementary concrete design tools

• Comprehensive concrete design ecosystem

🆕 What’s New in Version 2026.0

• Enhanced Moment Redistribution – Improved plastic analysis with better convergence

• Expanded Code Coverage – Latest updates to ACI 318, CSA A23.3, and Eurocode 2

• Variable Section Enhancements – More flexible haunched and tapered beam options

• Reinforcement Optimization – Advanced algorithms for bar selection and spacing

• Report Generation Upgrades – More comprehensive and customizable reports

• UI/UX Refinements – Streamlined workflow with continuous beam-specific workspace

• Performance Optimizations – Faster analysis for complex multi-span systems

• Stability Improvements – Bug fixes and reliability enhancements
