Crosslight APSYS 2023

APSYS software is a unique tool in advanced simulation of physical models of semiconductor devices. This software performs electrical, optical and thermal analyses of semiconductor devices simultaneously based on finite element (FEM) and finite difference time domain (FDTD) numerical methods in two and three dimensions.

The simulation structure in APSYS software is based on band structure engineering and quantum mechanical effects. Also, this software includes various modules for optical simulation, which has made APSYS attract the attention of many researchers in the simulation of optical devices.

APSYS Applications

This software has very wide applications and can simulate almost all semiconductor devices:

• LED, OLED, and AMOLED light-emitting diodes
• Organic, hybrid, thin-film and multi-junction solar cells
• Photodetectors (PD) and infrared quantum well photodetectors (QWIP)
• Bipolar transistors, HEMT, HBT, MOSFET, and MESFET
• Diode devices and resonant tunneling diodes (RTDs)
• MOS devices with quantum mechanical effects (Quantum-MOS)
• Power-based devices (GaN)
• Electro-absorption modulators

The only limitation of APSYS software is that it does not use the photon rate relationship for modeling laser devices. Therefore, PICS3D software has been designed and provided for this application.

APSYS Capabilities

APSYS software has an extensive library of materials and uses hydrodynamic, optical, drift-diffusion, thermionic diffusion, quantum transport and tunneling, heat transfer, Poole-Frankel, and temperature-dependent simulation models. The simulation of the aforementioned models in this software is performed simultaneously.

It is worth noting that the convergence of numerical simulation in this software has industrial considerations. The data obtained from the simulation with APSYS software is as follows:

• Current versus voltage (IV) characteristics
• Two-dimensional electric potential, electric field, and current distribution
• Two-dimensional distribution of electron and hole concentrations
• Two-dimensional distribution of heat carriers in a hydrodynamic model
• Two-dimensional network temperature distribution for heat transfer model
• Band structure under different bias conditions
• AC small signal analysis in any frequency range
• Extraction of AC parameters such as S and Y parameters
• Quantum well subband structure with capacitance combination model for quantum devices
• Two-dimensional distribution of occupation and concentration of deep traps in semiconductors
• Two-dimensional optical field distribution for photonic devices such as optical sensors
• Spontaneous emission spectra as a function of current for LED and OLED
• All of the above as a function of time (Transient model)
• All of the above in different temperature conditions

Pars Optics Specialized Group has provided APSYS software with scientific guarantee for the research and development of semiconductor optical devices in the following versions.

• APSYS software version 2023
• APSYS software version 2018

The APSYS software suite includes ready-made educational projects for all of the above tools, educational videos and PDFs. Software purchase and delivery is online. Some of the projects in this valuable suite are as follows:

YOU ARE:

– OLED in AMOLED (m-MTDATA/alpha-NPD/Alq3/LiF/Al/Ag)
– Bilayer OLED (NPB/Alq3 OLED)
– EL/Absorption Spectrum Model for OLED (Alq3 and Alq3:DCM)
– Fitting EL Spectrum of Organic Materials
– Low-voltage electrolumiscent device (PIN Organic LED w/Alq3)
– Opticalled pumped OLED (TPD/CBP/F8BT/SiO2)
– OLED with resonant cavity effect (CuPc/TPD/Alq3/LiF)
– Tandem OLED with resonant cavity effect (NPB, Alq3, DCJTB:Alq3, n-doped Alq3 and p-doped NPB)
– Trilayer OLED (NPB/Alq3/Alq3:DCM)
– WOLED with exciton diffusion model (ITO/NPD/BCzVBi:CBP/Ir(ppy)/BPhen)

Solar Cell:

– Quantum dot solar cell (InAs/GaAs dot)
– Amorphous/micro-crystal silicon tandem cells (Ag/ZnO/muC-Si-PIN/a-Si/ITO)
– Amorphous SiC and SiGe triple junction tandem cells (muC-Si/a-SiGe/a-SiC)
– Amorphous SiGe triple junction tandem cells (a-SiGe/a-SiGe/a-Si)
– Amorphous/micro-crystal silicon tandem cells, ITO as semiconductor (Ag/ZnO/muC-Si-PIN/a-Si/ITO)
– InN solar cell (Mg-doped InN layer with an electrolyte layer)
– FDTD simulation with light source through thick glass (p-i-n silicon solar cell)
– ۳D models of triple junction solar cell powered by focused beam (3D triple junction – with tunnel junction)
– ۳D focused beam model with beam from z-direction (3D triple junction – with tunnel junction.)
– CsSe-CIGS cell simulation (CdSe – CuInGaSe layers)
– Triple junction solar cell simulation with diffraction model (2D triple junction)
– InGaN/Si solar cell (heterojunction solar cell)
– GaInP/GaAs/GaInAs solar cell simulation for EQE computation (2D triple junction – with tunnel junction)
– Triple junction solar cell simulation, multiple light source (2D triple junction – with tunnel junction)
– Triple junction solar cell thermal simulation (2D triple junction – with tunnel junction)
– Silicon solar cell simulation with imported doping profile (1D silicon p-n junction)
– Computing IQE versus wavelength for solar cell (silicon P(+)P(-)N structure)
– Modeling of RCC solar cell with laser fired contact
– Silicon solar cell simulation with Schottky & tunneling (1D silicon p-n junction)
– Silicon PERT Cell (Passivated emitter, rear totally diffused (PERT))
– Silicon wafer photo-current lifetime calibration (2D Si wafer, lightly n-doped)
– Simple PIN-like solar cell based on Si or poly Si (2D silicon PIN)
– Silicon Rear Contacted cell (RCC) simulation (2D Si RCC structure with double coating layers)
– Ray-tracing (RT) technique for comparison (RCC structure)
– ۳D textured thinfilm tandem cell (a-Si/muc-Si tandem cell with pyramid texture)
– PIN-like solar cell based on alpha-Si, or amorphous Si (2D silicon PIN)
