midas GeoXD 2020 v1.1

midas GeoXD is designed for those who pursues the most efficient workflow for shoring design. Every aspect has been developed based on our practical philosophy. This drawing assistant will set you free from repetitive drawing works and any possible errors.

You can assign the style of retaining wall, strut, king post and other support systems to your lines directly with Drag & Drop function.

You can define the support systems to your retaining system easily with auto alignment function such as strutting for general and corner / adjusting level of strut and waler / amending the toe and head level of retaining wall / excavation area.

GeoXD can support to generate the drawing of construction stage until final excavation level.

You can generate the drawings with just one click and export with dwg format.

GeoXD can support to export fpn file for geometry of 2D and 3D analysis with GTS NX.
